Lickogic

Lickogic board is an extension for the Arduino shield Midilickuino .. He adds 8 potentiometers (Panasonic 9mm square potentiometer EVUE series) to your MIDI application. Lickogic  connects directly to the BOARD connector of Midilickuino via Cablick16.

Up to 6 x Lickogic board can be connected in series with the two connectorsIN and OUT on the back for a total of 48 potentiometers. Lickogic can also be linked with Dilicktal board.

JP1 configures the analog input used. This configuration is done through a simple jumper (see Lickogic tutorial)

 Documentation

• Schematic
• Lickogic tutorial
