Dilicktal board is an extension for the Arduino MIDI shield Midilickuino. He adds 8 LEDs and 8 buttons on your MIDI application. Dilicktal  connects directly to the BOARD connector of Midilickuino via Cablick16.

More details

1 item in stock

Warning: Last items in stock!

18,90 € tax excl.

Dilicktal board is an extension for the Arduino MIDI shield Midilickuino. He adds 8 LEDs (red) and 8 buttons (ALPS 12mm square long life SKQE) on your MIDI application. Dilicktal connects directly to the  BOARD connector via  Cablick16.

Up to 8 x Dilicktal board can be connected in series with the two connectors IN and OUT on the back of it for a total of 64 buttons and 64 LEDs. It can be chained with Lickogic board.

The Dilicktal board has two shift register, a MC14021 and 74HC595 which can communicate with the 8 LEDs and 8 buttons with ShiftIN ShiftOUT Arduino functions  (see ShiftOUT and ShiftIN)
